Best energy efficient piston air compressor

  • Low specific power consumption
  • Imported piston rings for long life service intervals
  • Simple back-pressure relief valve for reducing initial torque on the motor
  • Overhung crankshaft with replaceable crank pin bush
  • Precisely machined one piece connecting rod
  • Less noise level and ease of maintenance.

Special Features

  • Crankshaft
  • Connecting Rod
  • Cylinder
  • Valve
  • Piston

Compressed air is a type of clean and environmental freindly energy.Frank's goal is to make the use of this energy easier by proposing solutions and systems that are the result of careful analysis of the needs of all potential users, distributors and their satisfication. We have widened and completed our range of air compressors, and accessories for aimed solutions.

Special Features

CrankShaft: Overhung crankshaft, with replaceable crankpin bush made from special steel material, is precision-ground and runs with minimum vibration. The crankshaft is balanced and rotates on two ball bearings.

Connecting Rod: Precisely machined, one piece connecting rod with solid construction does not require adjustment. Integral splash lubrication

Cylinder Cylinders are made from special cast iron material with deep radial fins on the outer side for quick heat dissipation. Each cylinder is separately cast, precision-bored and honed for smooth running.

Valve: Stainless steel finger valves are heat-treated, quick-acting. Concentric disc valve plates & spring are made from high quality steel material, having large flow area for longer valve-life and better performance, easy for removal & servicing.

Piston Equalized and balanced pistons are made from aluminium / cast iron material. Each piston has compression ring and oil control rings for optimum efficiency.
